In this guide, you’ll learn how to check the 2014 Jeep Cherokee transmission fluid level, when to replace the fluid, common symptoms of low transmission fluid, and maintenance tips to keep your transmission in excellent condition.
2014 Jeep Cherokee Transmission Fluid Level
Checking the transmission fluid level isn’t as simple as checking engine oil. Because the transmission is sealed, you’ll need the proper tools and follow the manufacturer’s procedure.
Tools You’ll Need
- Floor jack and jack stands or a vehicle lift
- Safety glasses and gloves
- Socket set
- Fluid pump
- Drain pan
- OBD-II scan tool capable of reading transmission fluid temperature
- Correct transmission fluid
Step 1: Warm the Transmission
Start the engine and drive the vehicle for approximately 10–15 minutes.
The transmission fluid should reach the specified inspection temperature, typically around 86°F–122°F (30°C–50°C) depending on the service procedure.
Always verify the required temperature range in the service manual.
Related Jeep Patriot Transmission Fluid Level Chart(For All Model Years)
Step 2: Park on a Level Surface
Park on a completely level surface.
Apply the parking brake and keep the engine running.
Step 3: Cycle Through All Gears
While holding the brake pedal:
- Shift into Reverse
- Shift into Drive
- Move through Manual mode if equipped
- Return to Park
Pause a few seconds in each gear to circulate transmission fluid.
Step 4: Monitor Transmission Temperature
Use an advanced scan tool to monitor transmission fluid temperature.
The fluid level must be checked only within the specified temperature range.
Related How to Check BMW Transmission Fluid Level(7 Easy Steps)
Step 5: Remove the Check Plug
Raise the vehicle safely.
Locate the transmission fill/check plug.
Carefully remove the plug.
Step 6: Inspect the Fluid Level
The fluid level is correct if:
- A small trickle of fluid flows from the opening.
If:
- No fluid comes out, the transmission is low.
- A large amount pours out, it may be overfilled.
Step 7: Add Fluid if Necessary
Use a fluid transfer pump to add transmission fluid until it begins to trickle from the check opening.
Reinstall the plug and tighten it to the manufacturer’s specified torque.
Related Best Time to Check Transmission Fluid(5 Routine Checks)
What Transmission Does the 2014 Jeep Cherokee Use?
Most 2014 Jeep Cherokee models sold in North America are equipped with the ZF 9HP48 9-speed automatic transmission. Depending on the trim and engine, this transmission is paired with either:
- 2.4L Tigershark MultiAir engine
- 3.2L Pentastar V6 engine
Unlike older automatic transmissions, the ZF 9-speed is a sealed transmission, meaning it does not include a traditional transmission dipstick.
Does the 2014 Jeep Cherokee Have a Transmission Dipstick?
No, the 2014 Jeep Cherokee does not have a standard transmission dipstick under the hood.
Instead, transmission fluid is checked through a fill/check plug located on the transmission housing. The fluid level must be verified using a specific procedure while monitoring transmission fluid temperature with a diagnostic scan tool.
This design helps reduce contamination and prevents incorrect fluid servicing.
Related Check Transmission Fluid When Hot or Cold
What Transmission Fluid Does a 2014 Jeep Cherokee Use?
The 2014 Jeep Cherokee with the 9-speed automatic requires:
Mopar ZF 8 & 9 Speed Automatic Transmission Fluid (or an equivalent fluid meeting Chrysler MS specifications for the ZF 9-speed transmission).
Using the wrong fluid can cause:
- Harsh shifting
- Delayed engagement
- Transmission slipping
- Premature internal wear
- Expensive repairs
Never substitute universal automatic transmission fluid unless it specifically states compatibility with the ZF 9-speed transmission.
Transmission Fluid Capacity
Capacity varies depending on the type of service.
Approximate capacities include:
- Drain and refill: About 4–6 quarts
- Complete overhaul or dry fill: Approximately 9–10 quarts
Actual capacity depends on how much fluid drains from the transmission.
Always refill according to the factory service procedure rather than relying solely on capacity numbers.
Symptoms of Low Transmission Fluid
Low transmission fluid can quickly damage the transmission if ignored.
Common symptoms include:
Delayed Gear Engagement
The vehicle hesitates before moving after shifting into Drive or Reverse.
Slipping Gears
The engine revs higher without a corresponding increase in speed.
Hard or Jerky Shifting
Gear changes become rough or abrupt.
Transmission Overheating
Low fluid reduces cooling, increasing transmission temperature.
Whining or Humming Noise
Insufficient lubrication may cause unusual transmission noises.
Warning Lights
Some vehicles may illuminate:
- Check Engine Light
- Transmission warning message
Diagnostic trouble codes may also be stored.
Symptoms of Overfilled Transmission Fluid
Too much transmission fluid can also create problems.
Signs include:
- Foamy transmission fluid
- Rough shifting
- Fluid leaks
- Overheating
- Erratic gear changes
Overfilled fluid becomes aerated, reducing lubrication effectiveness.
How Often Should Transmission Fluid Be Changed?
Jeep often lists the transmission as requiring minimal scheduled maintenance under normal driving conditions.
However, many transmission specialists recommend changing the fluid every:
- 60,000–80,000 miles under normal driving
- 40,000–60,000 miles for severe driving conditions
Severe conditions include:
- Frequent towing
- Mountain driving
- Heavy stop-and-go traffic
- Hot climates
- Off-road driving
Regular fluid changes help extend transmission life.
What Color Should Transmission Fluid Be?
Healthy transmission fluid should appear:
- Bright red
- Light amber
- Transparent
Fluid should be replaced if it becomes:
- Dark brown
- Nearly black
- Burnt-smelling
- Contaminated with metal particles
Dirty fluid reduces lubrication and increases wear.
Can You Check Transmission Fluid Without a Scan Tool?
Not accurately, because transmission fluid expands as it heats, the fluid level depends heavily on temperature.
Without monitoring transmission temperature, it’s easy to underfill or overfill the transmission.
A professional-grade scan tool is highly recommended.
Common Transmission Problems on the 2014 Jeep Cherokee
The 2014 model year experienced several transmission-related complaints, especially during its early production years.
Common issues include:
- Hesitation during acceleration
- Rough shifting
- Delayed engagement
- Unexpected downshifts
- Software-related shift problems
Many of these issues were addressed through transmission software updates rather than mechanical repairs.
If your Cherokee experiences shifting issues, checking for available software updates should be one of the first steps.
Tips for Extending Transmission Life
Proper maintenance can significantly increase transmission longevity.
Follow these best practices:
- Use only the recommended transmission fluid.
- Check for leaks regularly.
- Service the transmission at recommended intervals.
- Avoid aggressive acceleration when the transmission is cold.
- Tow only within the vehicle’s rated capacity.
- Address warning lights immediately.
- Keep the transmission properly cooled.
- Avoid overfilling or underfilling the fluid.
FAQs
How do I know if my 2014 Jeep Cherokee transmission fluid is low?
Common signs include delayed shifting, slipping gears, rough gear changes, transmission overheating, whining noises, and warning lights. A proper fluid level inspection requires checking the transmission through the fill plug at the specified fluid temperature.
Can I add transmission fluid myself?
Yes, but because the transmission is sealed, adding fluid requires lifting the vehicle, using a fluid pump, monitoring transmission temperature with a scan tool, and following the correct service procedure. It is more involved than servicing older vehicles with a dipstick.
What happens if I use the wrong transmission fluid?
Using the wrong fluid can cause poor shift quality, increased wear, overheating, slipping, and even transmission failure. Always use the manufacturer-approved fluid for the ZF 9-speed automatic transmission.
Is the 2014 Jeep Cherokee transmission sealed?
Yes. Most 2014 Jeep Cherokee models equipped with the 9-speed automatic have a sealed transmission without a conventional dipstick. Fluid level checks and refills must be performed through the transmission’s fill/check plug.
Final Thoughts
Checking the 2014 Jeep Cherokee transmission fluid level requires more than simply pulling a dipstick. Since the ZF 9-speed automatic transmission is sealed, the fluid must be inspected through the check plug while the transmission is within a specific temperature range. Although the process is more complex than on older vehicles, maintaining the correct fluid level is essential for smooth shifting, proper cooling, and long transmission life.
By using the correct transmission fluid, following recommended service intervals, and addressing leaks or shifting problems early, you can help keep your 2014 Jeep Cherokee transmission operating reliably for many miles.
