Ram ProMaster vans come with different engines and transmissions depending on the model year and configuration. Knowing the correct transmission fluid type and level for your specific vehicle is essential when performing maintenance or fluid replacement.
Below is a detailed Ram ProMaster transmission fluid level chart, organized by model year, engine type, transmission type, and recommended fluid capacity. These values are based on manufacturer specifications.
Ram ProMaster Transmission Fluid Level Chart
| Model Year | Engine Type | Transmission Type | Fluid Capacity (quarts) | Dipstick / Fill Method | Fluid Type |
|---|---|---|---|---|---|
| 2014 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2014 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2015 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2015 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2016 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2016 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2017 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2017 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2018 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2018 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2019 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2019 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2020 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2020 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2021 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2021 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2022 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2022 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
| 2023 | 3.6L V6 Pentastar | 62TE 6-speed automatic | 9.0 | Dipstick | ATF+4 |
| 2023 | 3.0L EcoDiesel I4 | AISIN 6-speed automatic | 8.5 | Fill plug | ATF+4 |
Notes on the Chart:
The dipstick method allows you to check the fluid level directly, while the fill plug method requires removing the transmission fill plug to ensure the correct fluid level.
Always check the fluid level when the transmission is at operating temperature, as levels vary when cold.
Use only the recommended ATF+4 fluid type to prevent damage and ensure proper operation.
Capacities are approximate and may vary slightly depending on axle ratio and optional equipment.
Related Transmission Fluid Dipstick Level(Complete Guide)
How to Check and Maintain Transmission Fluid
1. Transmission Fluid Check (Dipstick Method):
- Park on a level surface.
- Start the engine and let it reach normal operating temperature.
- Shift through all gears and return to park.
- With the engine running, remove the dipstick, wipe it clean, reinsert it, then remove it again to check the level.
- Add ATF+4 fluid if necessary, but avoid overfilling.
2. Transmission Fluid Check (Fill Plug Method):
- Vehicle must be on a level surface and at operating temperature.
- Remove the fill plug; fluid should be level with the bottom of the plug hole.
- Add fluid slowly until it begins to slightly drip from the fill hole.
- Reinstall the plug securely.
3. Transmission Fluid Change:
- Recommended interval is generally every 60,000–100,000 miles.
- Severe use, such as towing, may require more frequent changes.
- Always use ATF+4 fluid for optimal performance.
Related Transmission Fluid Level Chart(For All Types)
FAQs
How to check Promaster transmission fluid level?
Use the dipstick method for 62TE transmissions: warm the engine, shift through all gears, and check with the dipstick. For AISIN transmissions, remove the fill plug to confirm the fluid is level with the bottom of the hole.
How much transmission fluid does a Ram ProMaster hold?
Most 3.6L V6 62TE automatic transmissions hold around 9 quarts, while 3.0L EcoDiesel AISIN automatics hold around 8.5 quarts.
Related Check Allison Transmission Fluid Level(Step by Step)
What level should my transmission fluid be at?
Fluid should be between the “full” and “hot” marks on the dipstick for dipstick transmissions. For fill plug transmissions, fluid should just reach the bottom edge of the fill hole.
How to check transmission fluid on a 2019 Ram ProMaster 2500?
For a 2019 ProMaster 2500: if it has the 3.6L V6 62TE automatic, use the dipstick method when the engine is warm. If it’s a diesel AISIN transmission, remove the fill plug and ensure the fluid is level with the bottom of the hole.
How do I know if my van needs transmission fluid?
Signs include slipping gears, harsh or delayed shifting, overheating, strange noises, or dark/burnt-smelling fluid.
How much transmission fluid does a 2019 Ram ProMaster 3500 hold?
- 3.6L V6 62TE automatic: approximately 9 quarts.
- 3.0L EcoDiesel AISIN automatic: approximately 8.5 quarts.
Final Thoughts
Keeping your Ram ProMaster transmission fluid at the correct level is vital for reliable performance and long-term durability. Whether your van has a 3.6L V6 Pentastar engine or a 3.0L EcoDiesel I4, maintaining proper fluid levels and using the recommended ATF+4 ensures smooth shifting, reduces wear, and prevents costly repairs.
Always check your owner’s manual for exact specifications, fluid type, and maintenance intervals, and inspect your transmission fluid regularly to maintain optimal performance.
